Selecting the Right Arrow Vanes for Compound Bows

In 1954, inventors William and Frederick Folberth applied for a patent on “arrow vanes.” In the product description within the patent application, the Folberths noted that “it is more desirable to fletch arrows with vanes composed of celluloid or other plastic sheeting material rather than feathers.”

Like feathers, vanes provide steering for an arrow. Unlike feathers, plastic vanes are impervious to weather, and they’re much more durable.

Through the years, archers and bowhunters have found that, particularly when shot from compound bows, different arrows require different degrees of steering depending on the shooting application. Indoors versus outdoors. Broadheads versus field points. Long-range shooting versus short-range, and so on.

Because of that variation you’ll see vanes of all shapes, sizes and materials in the fletching aisle at your favorite archery pro shop. The only true way to figure out which ones will work best for your situation is to experiment with different vanes. But there are some general rules of thumb that can help guide your selection. Let’s start with vane length.

Length

The longer the vane, the more steering it provides. But the more steering it provides, the more drag it creates.

So, while a 4-inch vane is ideal for use on large-diameter arrows used for indoor practice or competition at 20 yards, it’s going to cause too much drag on a small-diameter arrow used for 50-meter outdoor shooting. On the outdoor arrow, you’d be better served by a 1 1/2- or 2-inch vane.

For a hunting arrow carrying a fixed-blade broadhead, you’ll probably want to be in the middle of the road with a 2- or 3-inch vane. That should give you the steering you need for that broadhead, without robbing you of speed you might need for a 40- or 50-yard shot.

Profile

The higher the vane stands above the arrow shaft, the more steering it provides. Likewise, the more drag it creates. That’s why you’ll see target archers shooting 50 meters often using short, low-profile vanes, as compared with bowhunters using fixed-blade broadheads with taller vanes on their arrows.

Along with the profile, you’ll notice different shapes at the nock end of the vanes. Some will be rounded, while others will be cut at specific angles, commonly referred to as “shield cuts.” The cuts create more drag for steering, and they generate more noise. The noise won’t matter to a target archer, but it will to a bowhunter.

Material

Vanes on the market today are going to be either plastic or Mylar. What’s critical about the construction is the stiffness. Vanes that are very flexible — like Mylar vanes — are going to be forgiving and do an incredible job at steering your arrows. But they’re also going to be louder than stiff vanes and are going to create more drag.

In many cases, the stiffer vanes will be thicker than others, so they will add more weight to your arrow. But that’s not a universal truth. There are some new vanes on the market that are very stiff, but thin, so they’re still comparatively light. Stiff vanes are a great choice for steering fixed-blade broadheads and for maintaining long-range arrow speed.

Once you have your vanes selected, then you will determine how to configure them. There are several configurations to consider.

Number of Fletchings

The two most common configurations are to put three fletchings on the shaft or four. Using the exact same vanes, the four-fletch arrow is going to have better steering, but it’s going to fly slower, due to extra drag.

This is where experimentation is key. Maybe you can get the same amount of steering, but better speed, by using shorter, lower-profile vanes in four fletchings. Play around with vane length, profile, material and number to figure out how to get the arrow performance you want.

Straight, Offset, Helical

There are three ways to attach your vanes to an arrow shaft: straight, offset or helical. In a straight setup, the vane runs perfectly straight down the center of the shaft. An arrow will still spin with straight fletchings, but not much. Spinning is key for arrow stabilization.

With an offset configuration, the vane is simply turned left or right on the shaft. If the point end of the vane sits to the left of the nock end, that’s a left offset, and vice versa for a right offset. An offset promotes spin in a specific direction. The sharper the offset, the more the arrow spins.

Vanes are installed in a helical manner when the vane is curled around the shaft. A helical setting is almost always used in conjunction with an offset. The helical configuration promotes even more spin than a simple offset.

You might think that simply promoting as much spin as possible would be best, and that is what many top target archers strive for with their indoor arrows shot at 20 yards. But an arrow spinning a lot at long range will lead to instability at the back of the arrow. The arrow will start to oscillate, creating a parachute effect that will slow down the arrow — and that can affect accuracy.

So you should experiment with the orientation of your vanes on the shaft as you conduct your testing to find out what produces the best result for your setup in a given application. Basically, which vanes set in what configuration will give you the tightest, most consistent groupings?

Figure that out, and you’ve got the perfect recipe for whatever game you’re playing.
